OB3-30 3 Element Yagi 30m

OPTIBEAM   OB3-30 3 Element Yagi 30m

OB3-30   3 Element full sized Yagi 30m

Bands   30
Gain (dBd) *   5.8
Gain (dBi) **   12.9
F/B (dB)   33
VSWR
10,100 - 10,125 - 10,150   1,1 - 1,0 - 1,1

Elements (number)   3
Max. Elementlenght (m)   15.54
Boomlenght (m)   8.9
Turning Radius (m)   8.16
Feedlines (number)   1 Coax 50 Ohm
Weight (kg)   54
Windload at 130 km/h   884 N / 1,10 m² / 11,9 feet²

Price ***   1.888,00 EUR
* = average gain over dipol in free-space / for comparison: 2 el monobander 4 dBd, 3 el 5-6 dBd
** = average gain at 20m above ground (= dBd + 2.15 dB isotropic + about 5 dB ground reflection)
*** = outside EU minus 19% tax - subject to change
